ZT35R Range -Built-in Receiver Type 35MM Tubular Motor

R: Radio
Mechanic Limit
share:
Inquiry
Download PDF

Download

Download

Download

Download
Applications

lnner Structure Picture

Dimension Drawing

ZT35R Range -Built-in Receiver Type							Product Certificate
Motor Type	Rated Torque	Rated Speed	Tube Diameter	Rated Power Input	Rated Current	Running Time	Max Number of Turns	L1/L2
	N.m	rpm	mm	w	A	min	Turn	mm
230V/50HZ - Ip44
ZT35R-3/28	3	28	35	98	0.43	4	37	565/552
ZT35R-6/14	6	14	35	98	0.43	4	37	565/552
ZT35R-6/28	6	28	35	139	0.6	4	37	565/552
ZT35R-10/17	10	17	35	139	0.6	4	37	565/552
ZT35R-13/14	13	14	35	139	0.6	4	37	565/552
120V/60HZ- Ip44
ZT35R-3/33	3	33	35	101	0.84	4	37	615/602
ZT35R-6/17	6	17	35	101	0.84	4	37	615/602
ZT35R-6/33	6	33	35	128	1.06	4	37	615/602
ZT35R-10/21	10	21	35	128	1.06	4	37	615/602
ZT35R-13/15	13	15	35	128	1.06	4	37	615/602
